Our LLDPE tubes are made from high-quaity low-density polyethylene granules through advanced extrusion processes.They are lightweigh,fexible,nontoxic, andexhibit excelent chemical resistance,making them ideal for use in a variety of industrial and commercial aplications. LLDPE tubes also offer good impact strength andare resistant to cracking under stress.
Specifications
Specification
● Composition: Low-Density Polyethylene (LLDPE)
● Durometer: Approx. 44 Shore D
● Service temperature range: -40℃ to +60℃
● Fluid admitted: Water, air, various chemicals
Detailed instructions
| No. | Tube O.D (mm) |
Tube l.D (mm) |
Wall Thickness (mm) |
Working Pressure 23°C (Bar) |
Burst Pressure 23°C (Bar) |
Bend Radius (mm) |
| LLDPE0425 | 4 | 2.5 | 0.75 | 15 | 45 | 20 |
| LLDPE0420 | 4 | 2 | 1 | 21 | 63 | 18 |
| LLDPE0640 | 6 | 4 | 1 | 13 | 39 | 30 |
| LLDPE0860 | 8 | 6 | 1 | 10 | 30 | 40 |
| LLDPE0855 | 8 | 5.5 | 1.25 | 12 | 36 | 40 |
| LLDPE1080 | 10 | 8 | 1 | 7 | 21 | 60 |
| LLDPE1075 | 10 | 7.5 | 1.25 | 10 | 30 | 60 |
| LLDPE1070 | 10 | 7 | 1.5 | 11 | 33 | 60 |
| LLDPE1210 | 12 | 10 | 1 | 6 | 18 | 80 |
| LLDPE1290 | 12 | 9 | 1.5 | 10 | 30 | 65 |
| LLDPE1411 | 14 | 11 | 1.5 | 8 | 24 | 80 |
| LLDPE1613 | 16 | 13 | 1.5 | 7 | 21 | 110 |
| LLDPE1612 | 16 | 12 | 2 | 9 | 27 | 100 |
▲ The above listings are only the most basic sizes or styles of the products we offer you. We support customization, please contact us.
Color
| Black | Dark blue | Blue | Clear blue | Clear | Green | Red | Orange | Yellow |
▲ You can use the Pantone Matching System to help us determine the color you want.
Benefits & Features
Features
The LLDPE tube is lightweight and fexible, making it easy to installeven in tight spaces. tis highly resistant to acids, alkalis, and various solvents. The tubing is also
food-grade compliant, making it suitable for beverage and potable water applications.
Applications
- Water supply and irrigation systems
- Chemical transportation lines
- Cable and wire insulation or protection
- Pneumatic control systems
- Laboratory tubing
- Agricultural and gardening applications
