Reinforced PVC Hose Specifications
Our reinforced vinyl hose is chemical, oxidation, and contamination resistant, and is compatible with most gases, fuels, oils, and low-grade acids. It can be reliably and repeatedly sterilized via gamma or EtO.
Specifications
- Temperature range: -30° to 150°F (-34° to 66°C)
- Vacuum rating: to 18” Hg
- Hardness: 80A durometer
- Working pressure: 3:1 safety factor
- Suggested fittings: barb
- Color: clear or else
- Packaging options: 100meters lengths; samples also available
Benefits & Features
Common Applications for Reinforced PVC tubing
- Our reinforced PVC tubing is used for a wide range of low- to high-pressure applications. The most common uses include:
- Soda, wine, beer, and other beverage dispensers
- Ink printers
- General laboratory
- Aerospace
- and many more
-
Custom Reinforced PVC Tube
We offer reinforced PVC tubing in a range of stock sizes. However, if none of these options is right for your application, Zhengyuanpu can provide custom reinforced PVC tube in OD/ID sizes to meet your unique needs. PVC tubing can be custom printed with the lettering or numbering you need for easy installation and identification. Custom cutting (to length), coiling, packaging, and other options are available. Contact us to discuss your custom tubing requirements.
