Our polyurethane single-layer, flame-retardant tubing is made from polyurethane-modified material with excellent flexibility, abrasion resistance and high tensile strength. The single-layer construction is complemented by a flame-retardant PVC overcoat for additional fire protection. This tubing withstands harsh environments and ensures safety in applications where fire performance is critical. It is ideal for pneumatic systems, wire protection and other industrial applications.
Specifications
Specification
● Composition: Polyurethane (PU)
● Durometer: Approx. 85-90 Shore A
● Service temperature range: -30℃ to +80℃
● Fluid admitted: Air, gases, and some chemicals
● Flame retardant standard: Meets UL 94 V-0
Detailed instructions
| No. | OD mm | ID mm | Thickness mm | Reel length | Net wright g/M | Burst pressure bar at 20℃ | Max working pressure bar at 20℃ | Min bend radius mm at 20℃ |
| 0425 | 4 | 2.5 | 0.75 | 200 | 9 | 25 | 10 | 10 |
| 0640 | 6 | 4 | 1 | 200 | 19 | 25 | 10 | 15 |
| 0850 | 8 | 5.5 | 1.25 | 100 | 33 | 25 | 10 | 25 |
| 1065 | 10 | 6.5 | 1.75 | 100 | 56 | 25 | 10 | 30 |
| 1280 | 12 | 8 | 2 | 100 | 77 | 25 | 10 | 35 |
| 1410 | 14 | 10 | 2 | 100 | 93 | 20 | 7 | 55 |
| 1612 | 16 | 12 | 2 | 100 | 108 | 20 | 7 | 65 |
▲ The above listings are only the most basic sizes or styles of the products we offer you. We support customization, please contact us.
Color
| Black |
▲You can use the Pantone Matching System to help us determine the color you want.
Benefits & Features
Features
- Flame Retardant: The use of polyurethane-modified materials ensures excellent fire resistance and prevents the spread of flames.
- Durability: High wear resistance and excellent tensile strength make this tubing highly durable and reliable.
- Flexibility: Offers superior flexibility for easy installation in confined spaces.
- Chemical Resistance: Resistant to oils, grease, and most industrial chemicals.
- Low Smoke Emission: When exposed to flame, the tubing emits minimal smoke and toxic fumes.
Applications
● Pneumatic systems
● Electrical wiring protection
● Automotive systems
● Industrial machinery
● Robotics
● Automation systems
● Fire safety applications
● Hazardous environments
